Equipments

　
Faculty of Systems Science and Technology
Department of Machine Intelligence and Systems Engineering

Advanced Machining Technology Laboratory
(Prof. Wu & Assoc. Prof. Nomura)

Equipment

＜Experimental Setup＞

	Ultrasonic assisted internal grinder Okamoto Machine Tools Works, Ltd. IGM15EX　(Internal grinder) Takesho Co., Ltd. URT40　(Ultrasonocally spindle)

	CNC surface grinder Nagase Integrex Co., Ltd. SGT-315RPA

	High speed/high precision machining center Kira Corporation Co., Ltd. SuperMil-2m

	3-axis control desktop ultrasonic assisted machine tool Takashima Sangyo Co., Ltd. MultiProⅢ (Machine tool) industria Co., Ltd. R2 (Ultrasonically spindle)

	Ultrasonic polisher Akita Seiko Co,. LTD

	Desktop polishing machine using MCF wheel

	Polishing machine using MCF FDK Co., LTD (Polishing machine) Asahifactory Corporation SL-0505 (Vibrator)

	Multi axis MCF polishing machine IAI Co., Ltd. TT-C3-4040

＜Measuring Machine＞

	Scanning electron microscope with four electron probes (3D-SEM) & Energy dispersive x-ray sepectrometer (EDX) Elionix Co., Ltd. ERA-8900 (3D-SEM) EDAX Inc. Genesis APEX (EDX)

	Non-contact 3D optical surface profiler Zygo Corporation New View 600

	Surface profiler Taylor Hobson Inc. Form Talysurf Intra

	Surface profiler Tokyo Seimitsu Co., Ltd. SURFCOM 480A

Color 3D laser microscope

KEYENCE Co., Ltd.
VK-8710

Scanning plobe microscope

Seiko Instruments Inc.
SPI3800M

Scanning electron microscope

TOPCON Co., Ltd.
SM-200

Digital microscope

KEYENCE Co., Ltd.
VHX-S15

Laser doppler vibrometer

Ono Sokki Co., Ltd.
LV-1610

Motion analyze microscope

KEYENCE Co., Ltd.
VW-6000

＜Software＞
COMSOL３	・Electro Magnetic Module ・Heat Transfer Module ・Structural Analysis Module	Magnetic field analysis，Heat transfer analysis，Structural Analysis
SOLID　EDGE　８		Structural Analysis
Solid Works 2011		Three dimensional modeling
PIEZO plus 4.0		Structural Analysis
FEMAP 8.2		Structural Analysis
